Installing The Power Mole

Getting started with the Power Mole is easy, but there are a few pointers that can prevent common mistakes.

  • Install the power mole on the non-movable part of your window.
  • Do not install the power mole over a window screen - adhere it directly to the glass.
  • The adhesive (3M VHB) will adhere strongly to the window. Ensure your window is clean and press it on there.

    Before attempting to power your outdoor device with the Power Mole, ensure that it is setup and working properly with its original power adapter. This helps ensure setup issues are closed when using the Power Mole.

    Next, choose a window location that is near an indoor outlet (up to 9 feet), as well as near the location you would like to install the outdoor device. Ensure the cable length is sufficient on both the indoor and outdoor side for your application. For the outdoor side, a USB extension or adapter cable can be used. Once you've verified the cable legnths, the outdoor device can be installed (mounted) in the desired location.

    We can install the Power Mole now. Starting with the receiver or outdoor side, plug in the USB connector first. The USB connector should be mounted with the connector facing down, which adds to weather robustness. By plugging in the USB connector, you can also verify that the USB plug will not interfere with window trim. Remove the adhesive backing and press firmly to the window.

    For the transmitter or indoor side, repeat the steps of removing the adhesive and placing the transmitter firmly on the window, directly opposite of the receiver. Next, plug in the Power Mole power adapter to the Power Mole transmitter and the indoor outlet. The transmitter red light should briefly turn on, indicating it is searching for a receiver. The red light will go off when it finds a receiver to power. At this point, the Power Mole is delivering power through your window!

    The Power Mole works through all types of glass, and can deliver 10 Watts of power through windows up to 30mm (1.18") thick. This solution works for all 5 Volt devices, including many cameras, lights and USB devices.

    Ring cameras require adapters, and the Power Mole adapter should not be plugged into a Ring camera directly. See the video below for details on Ring cameras, as well as another installation example:
